Water cut CNC centre PTV

  • Low longitudinal axis for better table stability, more precise cutting and easier access to the working area alongside the table.
  • Y-axis length 6m
  • Modular table construction
  • A new concept for the Z-axis for cutting materials up to 320 mm (3D) / 500 mm (2D) thick.
  • New design of CNC table and control panel with an emphasis on ergonomics and the use of high-resistance materials.
  • High and extremely robust structure.
  • Precise linear motions.
  • Hardened and ground toothed racks and pinions.
  • Extremely robust servomotors in combination with precise gears
  • Linear measurement system.
  • Service range lenght 6m, width 3m, height 0,8m
PTV WJ3060-1Z-Cobra-60°PJ

PTV WJ2040-1Z-Cobra-60°PJ
